16 Pc. 2LTE, 3L Timing Belt Kit for the Toyota Hilux, Prado, Surf with 2LT-II, 2LTE, 3L, 5L series engines
Kit contents = see product description
| Article number: | GVTO545 |
| Availability: | In stock (2) |
For use when replacing the cylinder head or head gasket. Head Gasket is not included. Please order separately.
Kit Contents:
Intake & Exhaust manifold gaskets
Exhaust Donut (manifold to pipe) - 2 pcs
Valve cover gasket (1)
Valve guide seals (8 pcs)
Camshaft oil seal
Injector washer/seal kit
Water neck housing (to block) gasket
Thermostat gasket
& several other small gaskets
Note 1: Head Gasket - is not included. The correct head gasket grade must be determined by the machine shop by measuring piston protrusion -OR- get the thickest gasket (F grade) however it's always best to take the measurements.
Note 2: 2LT-E and 3L engines use a different head gasket due to bore diameter differences and are not interchangeable. The 2.8L displacement 3L engine has a larger bore diameter.
Toyota pn:
04111-54103
04111-54104
GVTO545
Engine Australia - high quality aftermarket
8708.29
1,425
2023 10 12
0411154103
0411154104
